C-Mount Microscope Cameras

The most popular standard microscopy camera used throughout the industry and supplied by all manufacturers of microscopes.  All manufacturers of microscopes design their microscopes to accept standard c-mount microscope cameras.  These are, by far, the most convenient class of live image camera to use for microscopy and are usually supplied with excellent software.  If you buy the right camera (ie pay enough) they can give very good image quality but are unlikely to surpass that of a good quality DSLR camera with a good quality DSLR camera adapter.  This class of camera is specially designed for microscopy with microscopy appropriate live camera controls and software.  Technically speaking a c-mount  has a screw thread with a diameter of 1 inch (25.4mm) and 32 TPI (threads per inch). The “flange focal distance” is 17.52mm (0.69 inches). The C-Mount standard also defines the thread length as being 3.8mm.
Showing 14 of 14 results
  • HAS-DX High Speed Camera - Superfast  2000 fps at full HD, C-Mount USB3 . Max 100k fps

    HAS-DX High Speed Camera - Superfast  2000 fps at full HD, C-Mount USB3 . Max 100k fps

    HAS-DX High Speed Camera - Superfast  2000 fps at full HD
    • Manufactured by Ditect Japan
    • Choice of colour or monochrome cameras (choose monochrome for higher speeds)
    • 2000 FPS at 1920x1080 resolution!
    • Max resolution 1920x1080
    • 16 GB of internal memory
    • Up to 100,000 FPS at 1920x4 resolution
    • C-mount
    • USB 3.0 connection (PC / tablet)
    • Multi-camera connection, synchronisation and control are possible
    • 12V / 20W
    • Size: 82mm x 110mm x 185mm
    • Weight: 1.5 kg
    • Supplied System includes: Camera, software, USB 3.0 cable, AC adapter, trigger & sync cables
    • Large 4/3 inch Sensor
  • High Speed Camera HAS-D71 C-Mount USB3 Light Sensitive and Fast. Max 120k fps

    High Speed Camera HAS-D71 C-Mount USB3 Light Sensitive and Fast. Max 120k fps

    HAS-D71 High Speed Camera - Light Sensitive and Fast
    • Manufactured by Ditect Japan
    • 8,000 FPS at 640 x 480  resolution
    • Monochrome or colour
    • 16 GB of internal memory
    • Up to 120,000 FPS at 640 x 12 resolution
    • C-mount, minimum 1 micro sec exposure time
    • USB 3.0 connection (PC / tablet)
    • Multi-camera connection, synchronisation and control are possible
    • 12V / 20W with AC
    • Optional battery
    • Size: 73 mm x 118 mm x 187.4 mm
    • Weight: 1.2 kg
    • Supplied System includes: Camera, software, USB 3.0 cable, AC adapter, trigger & sync cables
    • 1/1.8 inch sensor
  • High Speed Camera HAS-D73 High Resolution, C-Mount USB3 Light Sensitive and Fast. Max 15k fps

    High Speed Camera HAS-D73 High Resolution, C-Mount USB3 Light Sensitive and Fast. Max 15k fps

    HAS-D73 High Speed Camera - Light Sensitive and Fast
    • Manufactured by Ditect Japan
    • 2,000 FPS at 1280x1028 resolution
    • Monochrome or colour
    • 16 GB of internal memory
    • Up to 15,000 FPS at 1280x116 resolution
    • C-mount, minimum 1 micro sec exposure time
    • USB 3.0 connection (PC / tablet)
    • Multi-camera connection, synchronisation and control are possible
    • 12V / 20W with AC
    • Optional battery
    • Size: 82mm x 110mm x 185mm
    • Weight: 1.32 kg
    • Supplied System includes: Camera, software, USB 3.0 cable, AC adapter, trigger & sync cables
    • Large 1 inch Sensor
  • High Speed Camera HAS-EF Fast, Compact, High Resolution, C-Mount USB3 . Max 14k fps

    High Speed Camera HAS-EF Fast, Compact, High Resolution, C-Mount USB3 . Max 14k fps

    HAS-EF High Speed Camera - Fast, Compact, High Resolution
    • Manufactured by Ditect Japan
    • Choice of colour or monochrome cameras (choose monochrome for higher speeds)
    • 500 FPS at 1920x1080 resolution
    • Max resolution 2560 x 2048 (5MP)
    • 6 GB of internal memory
    • Up to 14,000 FPS at 256x32 resolution
    • C-mount, minimum 100 micro sec exposure time
    • USB 3.0 connection (PC / tablet)
    • Multi-camera connection, synchronisation and control are possible
    • 12V / 12W
    • Size: 45.6mm x 98.5mm x 128mm
    • Weight: 0.5 kg
    • Supplied System includes: Camera, software, USB 3.0 cable, AC adapter, trigger & sync cables
    • Large 1 inch Sensor
  • High Speed Camera HAS-U2 Compact, High Resolution, C-Mount USB3 . Max 7.5k fps

    High Speed Camera HAS-U2 Compact, High Resolution, C-Mount USB3 . Max 7.5k fps

    HAS-U2 High Speed Camera - Compact, High Resolution
    • Manufactured by Ditect Japan
    • Choice of colour or monochrome cameras (choose monochrome for higher speeds)
    • 250 FPS at 1920x1080 resolution
    • Max resolution 2592 x 2048 (5MP)
    • 2 GB of internal memory
    • Up to 7,500 FPS at 320x20 resolution
    • C-mount, minimum 10 micro sec exposure time
    • USB 3.0 connection (PC / tablet) Micro-B Interface
    • Multi-camera connection, synchronisation and control are possible
    • 5V / <4.5W
    • Size: 44mm x 44mm x 81.5mm
    • Weight: 0.21 kg
    • Supplied System includes: Camera, software, USB 3.0 cable, AC adapter, trigger & sync cables
    • Large 1 inch Sensor
  • IUA Series High Speed Cameras 98 to 523 fps C-Mount USB3 Colour & Monochrome Versions

    IUA Series High Speed Cameras 98 to 523 fps C-Mount USB3 Colour & Monochrome Versions

    IUA Series Machine Vision, USB3, High Speed Camera Series
    Speeds from 98 to 523 frames per second

    Summary

    • Choice of colour or monochrome cameras (choose monochrome for higher speeds)
    • Speeds from 98 to 523 frames per second
    • Choose resolutions from 0.39 to 7.1MP
    • Extremely Compact Design
    • C-Mount
    • Supplied with ToupView control and analysis software
    • Supplied with Windows/Linux/OSX multiplatform SDK
    • Supports native C/C++, C#/VB.Net, DirectShow, Twain API
    • Supports external triggering, digital I/O and free-running modes
    • Supports RO
    • 1.5MPI, flip, bit-depth switching and other features
    • Uses USB3.0 to transmit uncompressed images in real time
    • Provides image acquisition and parameter setting (such as working mode, image parameter adjustment etc.) through client-side user-friendly software
    • USB 3.0 connection
    • Size: 80 x 80 x 45mm
    • Lightweight
    • Supplied System includes: Camera, software, USB 3.0 cable
    • IMX273 series sensors
    • Lenses, Illumination, microscopes and microscope adapters can be supplied
  • UM-HF-M220 High Speed Camera, High Res, C-Mount GBit, Fast. Max 16.9k fps

    UM-HF-M220 High Speed Camera, High Res, C-Mount GBit, Fast. Max 16.9k fps

    Revealer M Series high-speed Cameras bring together unique CMOS image sensor technologies and extensive high-speed digital imaging expertise to provide a camera with the flexibility to be used in a wide variety of applications such as high-precision scientific research, national defence, and high-speed industrial fields etc.

    This series has top performance, special functions and powerful capabilities of data transmission / storage / processing, can help you precisely freeze "key moments" of each frame, and recording rates up to 25,000fps are available at reduced image resolutions.

  • UM-X-213 High Speed Camera, High Res, C-Mount GBit, Fast. Max 16.9k fps

    UM-X-213 High Speed Camera, High Res, C-Mount GBit, Fast. Max 16.9k fps

    Revealer X Series high-speed Cameras are high quality, high speed devices built by Qianyanlang designed for scientific research.  Equipped with high a transfer bandwidth of up to 16GB/s delivering powerful data collection and processing capabilities.

    The key advantages of this technology are massive data throughput (1280x1024 at 13,600 FPS), professional image quality incorporating a dedicated ISP processing chip with automatic white balance, colour correction, gamma, defogging, denoising, sharpening and other modules.
